Specialized in Wet Mix Plant Manufacturer
We are among the top Wet Mix Macadam Plant, Wet Mix Plant, Wet Mix Macadam Plant Supplier & Manufacturers in the world for plants and have considerable experience in creating other building material plants and machinery.
| PARAMETERS |
UNIT |
AEWD-250 |
AEWD-300 |
AEWD-350 |
| Output Capacity | TPH | 250 | 300 | 350 |
| Four Been Feeder | ||||
| Capacity | Cum. | 48 | 48 | 48 |
| Loading Width | Mtr. | 3 | 3.2 | 3.2 |
| Auxiliary Conveyor | mm/hp | 550/3 | 600/5 | 600/5 |
| Collecting Chonveyor | mm/hp | 750/10 | 800/12.5 | 800/12.5 |
| Vibrator for fine Agg. Bin | Hp | 1 | 1 | 1 |
| Pug Mill (Mixer) | ||||
| Capacity | Cum. | 2.75 | 2.75 | 2.75 |
| No. of Arms Pair | Nos. | 15(30) | 17(34) | 17(34) |
| Connected Load | HP | 40 | 50 | 60 |
| Water Pump | HP | 3 | 5 | 5 |
| Hydraulic Power Pack | HP | 3 | 5 | 5 |
| Gob Hopper | Kgs. | 2000 | NA | NA |
| Load out Conveyor 11 mtr Long | MM/HP | 750/12.5 | 900/15 | 900/15 |
| Storage Silo (Optional) | Ton | 30 | 30/50 | 30/50 |
| Load out Conveyor 18.3 mtr Long | MM/HP | 750/12.5 | 900/15 | 900/15 |
| Vibrating Screen (Optional) | HP | 3 | 5 | 5 |
| Slinger Conveyor (Optional) | HP | 750/10 | 800/12.5 | 800/12.5 |
| Total Connected Load | HP | 81.5 | 108.5 | 118.5 |
Benefits of Wet Mix Plant
Produces a lot of mix quickly
Easy to use and operate
Works efficiently and is easy to maintain
Has the latest technology and international standards
Key Features of Wet Mix Plant
Makes high-quality mix
Available in portable and stationary models
Accurate feeder for aggregates and additives
Spare parts are reliable and easy to get
Easy to lubricate and maintain
4-Bin Feeder with spiral opening and individual belts for controlled flow
Vibrating Screen removes oversized aggregate for better mix quality
Slinger Conveyor feeds the pug mill with a 600 mm wide belt
Pug Mill mixes aggregates and additives quickly and consistently
Water Tank holds 15/20 MT of water, made from steel plates with necessary features
Mineral Filler supports the required amount of additives to the pug mill
Control Cabin is a fully programmed control panel, allowing the operator to control production from a comfortable, air-conditioned space.
Wet Mix Plant Supplier Ahmedabad — One Of India’s Leading Road Construction Equipment Manufacturing Company & Supplier of Wet Mix Macadam Plant, Wet Mix Plant In Ahmedabad at Best price. Wet Mix Macadam Plant is also known as WMM Plant is for the base and sub base. In terms of operational costs and quality control, its unique design makes it the most efficient. Available in fixed or inconsistent speed drives. The plant is well equipped with flexible gates at its bins.
The design of twin shaft pug mill ensures fast, continuous, homogeneous mixing of entireties & additives. Besides, the tide hopper arrangement allows release into trucks without shut down & spillage. While manufacturing our offered product has uniform mixing of aggregate, accurate blending, proper discharge of product without any segregation and binding of additive are the main objective. Confirmation to the international standard the offered range of Wet mix plant also conforms fully to the latest MORTH specification. Our WM plant provides you with all advanced process control and automation, the latest proven technical solution plant installation at site with fully system support. It is also useful highly for road construction purpose.
Our offered range is available from 60-200 TPH. High fuel resistance with optimal mixing capacity these plants are available for our customer in various specifications. Moreover, we offer this wet mix plant to our valuable customer at competitive prices. Wet Mix Plant is designed to take an overload of 20 in continuous operation without affecting the quality of the WMM Plants, Wet Mix Plant, Wet Mix Plant Wmm Plant, Wet Mix Macadam Plant Due to low power requirement in plant, Canada, Mauritius.
Standard Components of Wet Mix Plant
- Asphalt Tank
- Control Cabin
- Control Panel
- Thermic Oil Heater
- Fuel Service Tank
- Bag House Dry Dust Collector
- Multiple Cold Aggregate Feeder Bins
- Batching Tower
- Cold Aggregate Slinger Conveyor
- Single Deck Scalping Screen
- Dryer Burner
- Rotary Drying Drum
Salient Features of Wet Mix Plant
- Minimal noise generation
- High Accuracy
- High Fuel Resistance
- Easy to Use
- Fine quality
- Durability
- Resistance to damage
